Continuity spray sterilization machine introduced

Continuous spray sterilizing machine is designed for dairy, juice, beverage, beer, food, medicine and other products after bottling or packaging design pasteurization equipment, materials through sterilization and cooling to extend the shelf life of the device over the purpose, especially in automated production lines necessary secondary sterilization equipment. According to users of different products for heating, sterilization, warm and cooling requirements of different processes, different process design, meet the technical requirements, according to user requirements, configure the high-precision automatic control system.

Continuity spray sterilization machine classification

1, automatic spray sterilization machine: the use of advanced PLC automatic computer control, can be set according to process requirements, the whole process of operation of the production control.

2, semi-automatic spray sterilization machine: the whole process of operation is the use of semi-automatic control. The operator can be controlled from the control panel for each of the pumps, valves and back flow function, the PID (Temperature Control) to maintain the sterilization temperature, sterilization temperature changes have accurate records on the recorder.

Continuity spray sterilization machine features

1, equipment rack made of stainless steel, the overall structure is compact, beautiful appearance of health;

2, high-quality plastic mesh belt chain plate, long-term work at high temperatures (≯98), short-term high temperature 104 ℃;

3, wide-angle full cone nozzles, flow distribution uniform and stable temperature field constant;

4, a variety of heat recovery technology energy utilization, energy conservation, and environmental protection;

5, the temperature sensor Pt100, high accuracy up to ± 0.5 ℃;

6, multi-process composition, process and reasonable, it can handle a variety of materials;

7, sterilization temperature by PLC touch screen control.

8, the total processing time frequency control can be adjusted according to the production process;

9, for packaging non-circular PP bottles, plastic bags, roof boxes, bottles, cans and other products configure automatic feeding and discharging mechanism, and automated conveyor lines connected to a smooth transition;

10, can provide users with heat distribution testing services, use of expert systems, on-line monitoring of the entire production process of temperature changes.

Continuity spray sterilizing machine uses:

Continuous spray sterilizing machine is mainly used for a variety of bottled, canned drinks, canned fruits and vegetables atmospheric sterilization, it can also be used PET polyester bottles of tea drinks, juice drinks after cooling after hot filling and sparkling beverages, warm beer bottle.
